| Camera Spec | |
|---|---|
| Signal System | 3G-SDI: 1080P60, 1080P30, 1080P25 HDMI: KP30, 4KP25, 1080P60, 1080P30, 1080P25 |
| Sensor | 1/2.5-inch CMOS, Effective Pixels: 8.51 MP |
| Scanning Mode | Progressive |
| Lens | 12X, f=4.4mm~52.8mm, F1.8~F2.6 |
| Digital Zoom | 16X |
| Minimum Illumination | 0.5Lux @ (F1.8, AGC ON) |
| Shutter | 1/30s ~ 1/10000s |
| White Balance | Auto, Indoor, Outdoor, One Push, Manual, VAR |
| Digital Noise Reduction | 2D & 3D Digital Noise Reduction |
| SNR | ≥ 55dB |
| Horizontal FOV | 71° ~ 8.2° |
| Vertical FOV | 42.7° ~ 4.5° |
| Pan Angle | ±170° |
| Tilt Angle | -30° ~ +30° |
| Pan Speed | 2.7° ~ 35.7°/s |
| Tilt Speed | 2.7° ~ 31.5°/s |
| Image Flip & Freeze | Support |
| PoE | Support |
| Preset Position | 255 |
| Preset Accuracy | 0.1° |
| Network Spec | |
| Video Compression | H.264 / H.265 / MJPEG |
| Video Stream | First Stream, Second Stream |
| First Stream Resolution | 3840×2160, 1920×1080, 1280×720, 1024×576 etc. |
| Second Stream Resolution | 1920×1080, 1280×720, 1024×576, 720×576 etc. |
| Video Bit Rate | 32Kbps ~ 102400Kbps |
| Frame Rate | 50Hz: 1fps ~ 25fps, 60Hz: 1fps ~ 30fps |
| Audio Compression | AAC |
| Audio Bit Rate | 96Kbps, 128Kbps, 256Kbps |
| Protocols | TCP/IP, HTTP, RTSP, RTMP, Onvif, DHCP, Multicast |
| USB Spec | |
| Operating System Supported | Windows 7/8/10, Mac OS X, Linux 2.4.6+, Android |
| Color System / Compression | YUY2 / H.264 / MJPEG |
| Video Format | YUY2: Max1080P30 MJPEG: Max2160P30 H.264: Max2160P30 |
| USB Audio | Support |
| USB Video Class (UVC) | UVC 1.1 |
| UVC PTZ Control | Support |
| Input / Output Interface | |
| HD Output | 1 × HDMI Version 1.4b 1 × SDI 1080P High-definition Output |
| USB Interface | 1 × USB 3.0 Type-B |
| Network Interface | 1 × RJ45 10M/100M Adaptive Ethernet, Support PoE |
| Audio Interface | 1 × Line In, 3.5mm Jack |
| Control Interface | RS485, RS232 IN/OUT |
| Power Interface | JEITA Type (DC IN 12V) |
| Generic Spec | |
| Input Voltage | DC 12V / PoE (802.3af) |
| Input Current | 1.0A |
| Operating Temperature | -0°C ~ 40°C |
| Storage Temperature | -40°C ~ 60°C |
| Power Consumption | 12W |
| Dimensions (W × D × H) | 238 × 167.2 × 149 mm |
| Net Weight | 1.4kg |
